Product Description
10" heavy duty kingpinless swivel caster10" x 3" crowned ductile iron wheel with roller bearings
Crowned tread for enhanced ergonomics
6,000 pound capacity
11-1/2" mounting height
9-1/8" swivel radius
4-1/2" x 6-1/4" top plate
2-7/16" x 4-15/16" slotted to 3-3/8" x 5-1/4" bolt holes
Zinc Plated
Ductile steel is a combination of special alloys that give
it higher weight capacities than cast iron, and is more
economical than drop forged steel. Comes with thick
walled, heavy duty core, hub & tread face.
Tensile strength of 45,000 PSI.
Product Videos
Custom Field
Caster Type Swivel
Wheel Diameter 10"
Tread Width 3"
Brake No
Mounting Type Top Plate
Mounting Size 4-1/2" x 6-1/4"
Bolt Hole Pattern 2-7/16" x 4-15/16" to 3-3/8" x 5-1/4"
Wheel Material Ductile Iron
Overall Height 11-1/2"
Load Capacity 6,000 lbs
Finish Zinc
Wheel Bearing Roller Bearing
