Product Description
Hamilton CH Series Champion rigid caster
8" x 3" Phenolic wheel with precision ball bearings
3,000-pound capacity
10 1/2" mounting height
5-1/4" x 7-1/4" top plate
3-3/8" x 5-1/4" slotted to 4-1/8" x 6-1/8" bolt hole pattern
1-2 week lead time
**REPLACES R-CH-83PH**
Product Videos
Custom Field
Caster Type Rigid
Wheel Diameter 8"
Tread Width 3"
Brake No
Mounting Type Top Plate
Mounting Size 5-1/4" x 7-1/4"
Bolt Hole Pattern 3-3/8" x 5-1/4" to 4-1/8" x 6-1/8"
Wheel Material Phenolic
Overall Height 10-1/2"
Load Capacity 3,000 lbs
Finish Platinum powder coat
Wheel Bearing Precision Ball Bearings
