S-FM-83RH Hamilton ForgeMaster Swivel Caster Moldon Rubber Wheel
S-FM-83RH Hamilton ForgeMaster Swivel Caster Moldon Rubber WheelMost or all components made in the USA

S-FM-83RH Hamilton ForgeMaster Swivel Caster Moldon Rubber Wheel

8" x 3" 95 Shore A Moldon Rubber wheel, 840 pound capacity
Item Number:
Your Price:

Product Description

Hamilton's ForgeMaster Casters were designed to match popular industry mounting plate, bolt hole and overall height specifications. However the precision tapered thrust bearing guaranteed-for-life integrally forged kingpin design makes it superior to the double ball raceways in its class.


  • Swivel Construction - 3/8" thick drop foged steel mounting plate, 5/16" x 2-1/2" plate steel legs
  • Kingpin - 1" diameter intrgrally forged with mounting plate guaranteed for life.
  • Main Load Bearing - CNC-machined 3-1/4" diameter raceway, 1/2" diameter hardened and polished steel bearings
  • Secondary Load Bearing - 1" precision tapered thrust bearing counteract radial thrust
  • Axle - 3/4" diameter hex head with lock nut
  • Lubrication Fittings - Ball-check type in swivel assembly and wheel hub
  • Finish - Hamilton red enamel
  • Capacity - 840 pounds
  • Mounting Height - 10-1/4"
  • Wheel Type - Moldon Rubber (95A) on cast iron wheel with precision ball bearings
  • Top Plate - 4-1/2" x 6-1/2"
  • Bolt Holes - 2-7/16" x 4-15/16" slotted to 3-3/8" x 5-1/2"
  • Swivel Offset - 2-1/4"
